| No. | Items | Specifications |
| 1 | Mode | Circumferential scanning/sector scanning/positioning |
| 2 | Rotating Range | 0~360°（optional for position limit） |
| 3 | Resolution | 0.01°（RMS） |
| 4 | Rotating Speed | 0～60rpm（Customized） |
| 5 | Angular acceleration | 60°/s2 |
| 6 | Pointing accuracy | ≤0.1° |
| 7 | Weight | ≤40kg |
| 8 | Max Load | ≥60kg |
| 9 | Power supply | AC220V/DC24V |
| 10 | Power Consumption | ≤200W |
| 11 | Communication Interface | RS422/RS232/RS485/RJ45 |
| 12 | Working Temperature | -40℃～+55℃ |
| 13 | Storage Temperature | -45℃～+65℃ |
| 14 | Wind resistance | Class 6/8 |
